norament
| Article Number |
3118 |
| Format |
Tile |
| Size |
1004 mm x 502 mm |
| Surface |
Relief Structure |
| CE Conformity (EN 14041) |
Manufacturer: nora systems GmbH, D-69469 Weinheim |
| DoP-No. (EN 14041) |
21 |
| UK DoP-No. (EN 14041) |
21 |
| Thermal conductivity (EN 10456) |
Fulfilled (λ = 0.17 W/(m·K)) |
| Dynamic Coefficient of Friction (EN 13893) |
Fulfilled (DS) |
| Reaction to fire (EN 13501-1) |
Bfl-s1, bonded (Not bonded) |
| Reaction to fire (EN 13501-1) |
Bfl-s1 (Bonded on mineral subfloor) |
| Thickness (EN ISO 24346) |
(Mean value ± 0.15 mm) 3.5 mm |
| Cigarette-burn resistance (EN 1399) |
Fulfilled (Procedure A (stubbed out) level ≥ 4, Procedure B (burning) level ≥ 3) |
| Flexibility (EN ISO 24344, procedure A) |
Fulfilled (Mandrel diameter 20 mm, no fissuring) |
| Hardness (ISO 48-4) |
82 Shore A (≥ 75 Shore A) |
| Residual indentation (EN ISO 24343) |
(Mean value ≤ 0.20 mm at thickness ≥ 3.0 mm) 0.12 mm |
| Abrasion resistance at 5 N load (ISO 4649, procedure A) |
(≤ 250 mm³) 115 mm³ |
| Colour fastness to artificial light (ISO 105-B02, procedure 3, test conditions 6.1 a)) |
Fulfilled Grey scale ≥ level 3 acc. to ISO 105-A02 (At least level 6 on the blue scale; ≥ level 3 on the grey scale) |
| Classification (EN ISO 10874) |
34/43 (Commercial/Industrial) |
| Toxicity of fire gases (DIN 53436) |
Carbonisation gases are non-toxic |
| Anti-slip properties (DIN EN 16165) |
R10 (According to DGUV 108-003) A,B |
| Improvement in footfall sound absorption (ISO 10140-3) |
10 dB |
| Effect of chemicals (EN ISO 26987) |
Resistant depending on concentration and time of exposure. In case of increased impact of oils, greases, acids, alkalis and other aggressive chemicals please contact us. |
| Electrical insulation properties (EN 1081 R1) |
> 10⁹ Ohm |
| Electrical propensity when walked upon (EN 1815) |
Antistatic, charging in case of rubber soles < 2 kV |
| Effect of a castor chair (EN ISO 4918) |
Suitable if castor wheels, type W, according to EN 12529 are used |
| Underfloor heating (EN 1264-2) |
Suitable, max. 35 C° |
| Environmental Product Declaration | |
| Disclosure of Product Ingredients |
Health Product Declaration |
| Indoor Air Quality & Environmental Certifications |
Blue Angel M1 Etiquetage A+ Austrian eco-label Indoor Air Comfort Gold Cradle to Cradle Certified Silver Singapore Green Building Product Global Green Tag eco-bau |
| Environmental Certifications |
Cradle to Cradle Silver |
| Embodied Carbon (Cradle to Gate) |
14.1 kg CO₂ eq./m² |
| Installation | |
| Maintenance | |
| NCS-Codes | |
| Warranty | |
| Manufacturing Location |
ISO 9001, 14001 & 50001 Certified Facilities in Germany |
