noraplan convia
| Article Number |
170F |
| Construction |
Homogeneous Rubber Compound |
| Class |
ASTM F1859 Standard Specification for Rubber Sheet Floor Covering without Backing |
| Product Specifications |
Smooth |
| Total Thickness |
2 mm |
| Format |
Sheet |
| Size |
1220 mm x 15.0 m |
| ∆IIC Sound Rating (ASTM E2179) |
ΔIIC 12 |
| ΔLw Sound Rating (ISO 10140-3) |
8 dB |
| Slip Resistance (ASTM D2047) |
>0.5 dry/wet required, ADA Compliant |
| Bacteria Resistance (ASTM 2180/ASTM G21) |
Resistant to bacteria, fungi and micro-organism activity |
| Latex Allergies (ASTM D6499) |
Inhibition ELISA, results are below detection level |
| Hardness (ASTM 2240) |
Shore type A |
| Static Load Limit (ASTM F970) |
≤ 0.005 in with 250 lbs required, Passes @ 800 psi |
| Rolling Load Limit (ASTM F2753) |
≤ 450 lbs. / sq. inch, with no forklift traffic |
| Abrasion Resistance (ASTM D3389) |
≤ 0.035 oz (1.0 g) required, Passes |
| Resistance to Heat (ASTM F1514) |
Passes |
| Radiant Flux (ASTM E648) |
Class 1 |
| Smoke Density (ASTM E662) |
< 450 |
| Thickness (ASTM F386) |
Passes |
| Resistance to Chemicals (ASTM F925) |
Passes |
| Static Generation (AATCC 134) |
< 1000 Volts at 20% RH |
| Thermal Transmission (ASTM C518) |
R-value of 0.04 |
| Embodied Carbon (Cradle to Gate) |
4.44 kg CO₂/M² |
| Biobased Content (ASTM D6866) |
32% |
| Indoor Air Quality | |
| Material Composition |
PVC-free and also free of added Formaldehyde, Heavy Metal Stabilizers and Ortho Phthalates and Halogenated Flame Retardants |
| Disclosure of Environmental Impacts | |
| Environmental Product Declaration | |
| Environmental Certifications |
Cradle to Cradle v3.1 Silver Greenhealth Approved PEFC Certified |
| LEED |
Contributes to multiple IEQ and MR Credits |
| Quantity per Roll |
196.9796 ft² (18.3 m²) |
| Weight per Roll |
137.89 lbs |
| Rolls per Pallet |
16 |
| Installation | |
| Maintenance | |
| Warranty | |
| Installation Method |
Directional |
| Wheel Types |
No metal or hard plastic wheels, the shape of the contact surface of wheels must be flat with round edges. The shore hardness must be Type A ≤90 |
| Storage |
Store within a temperature range of -5˚F (-21˚C) to 120˚F (49˚C) under the following conditions: pallets must remain intact with sheet goods standing on end, undamaged, and not stacked; goods must be in a permanently dry environment, with no direct sunlight. Adhesives and cold weld must remain at room temperature without freezing. |
| Manufacturing Location |
ISO 9001, 14001 & 45001 Certified Facilities in Germany |
| nora Guide Spec | |
| nora Flyer | |
| nora Viewbook |
N0052N |
