norament 825 round
| Article Number |
1902 |
| Construction |
Homogeneous Rubber Compound |
| Class |
ASTM F1344 Standard Specification for Rubber Floor Tile |
| Product Specifications |
Round Pastille |
| Format |
Tile |
| Size |
501 mm x 501 mm |
| ∆IIC Sound Rating (ASTM E2179) |
ΔIIC 16 |
| Slip Resistance (ASTM D2047) |
>0.5 dry/wet required, ADA Compliant |
| Bacteria Resistance (ASTM 2180/ASTM G21) |
Resistant to bacteria, fungi and micro-organism activity |
| Latex Allergies (ASTM D6499) |
Inhibition ELISA, results are below detection level |
| Hardness (ASTM 2240) |
Shore type A |
| Static Load Limit (ASTM F970) |
≤ 0.005 in with 250 lbs required, Passes @ 800 psi |
| Rolling Load Limit (ASTM F2753) |
≤ 550 lbs. / sq. inch, with no forklift traffic |
| Abrasion Resistance (ASTM D3389) |
≤ 0.035 oz (1.0 g) required, Passes |
| Resistance to Heat (ASTM F1514) |
Passes |
| Radiant Flux (ASTM E648) |
Class 1 |
| Smoke Density (ASTM E662) |
< 450 |
| Surface Burning (CAN/ULC-S102.2) |
FSC1 of 55 and SD of 450 |
| Size & Squareness (ASTM F2055) |
Passes |
| Thickness (ASTM F386) |
Passes |
| Dimensional Stability (ASTM F2199) |
Passes |
| Resistance to Chemicals (ASTM F925) |
Passes |
| Static Generation (AATCC 134) |
< 1000 Volts at 20% RH |
| Indoor Air Quality | |
| Material Composition |
PVC-free and also free of added Formaldehyde, Heavy Metal Stabilizers and Ortho Phthalates and Halogenated Flame Retardants |
| Environmental Product Declaration |
| Quantity per Piece |
2.69 ft (0.25 m²) |
| Weight per Piece |
2.6 lb |
| Installation | |
| Maintenance | |
| Warranty | |
| Installation Method |
Directional |
| Wheel Types |
No metal or hard plastic wheels, the shape of the contact surface of wheels must be flat with round edges. The shore hardness must be Type A ≤90 |
| Storage |
Store within a temperature range of -5˚F (-21˚C) to 120˚F (49˚C) under the following conditions: pallets must remain intact with sheet goods standing on end, undamaged, and not stacked; goods must be in a permanently dry environment, with no direct sunlight. Adhesives and cold weld must remain at room temperature without freezing. |
| Manufacturing Location |
ISO 9001, 14001 & 45001 Certified Facilities in Germany |
