Layout
Floor Design Tool
Interlaced Collection

Looped

Color:
Please select

Why we love this collection

Interlaced Collection

Interlaced™ Collection’s three monolithic vinyl sheet styles – Meshed™, Crossed™ and Looped™ – take patterning cues from natural fabrics in eight nature-inspired colors. These products provide the design flexibility to create attractive, hard-working and supportive spaces that improve operational efficiencies and wellness – helping you reach your facilities goals.

Product Number

A01

Product Construction

Heterogeneous Vinyl Sheet

Type/ Grade / ASTM F1303

Type I, Grade 1

Wear Layer Thickness (ASTM F410)

28 mil

Total Thickness (ASTM F386)

2.5 mm

Backing Class

Class B

Finish

28 MIL WITH CERAMOR

Nominal Dimensions

1.83 m x 18 m (6 ft x 59.06 ft)

Usable Dimensions

1.80 m x 18 m (5 ft 11 in x 59.06 ft)

IIC Sound Rating

(ASTM E492-09) 58 IIC

Delta IIC Sound Rating

(ASTM E2179) Δ 11 IIC

Slip Resistance

(ASTM D2047) >0.55 wet/dry, ADA Compliant

Static Load Limit

(ASTM F970) 1000 psi

Rolling Load Limit

(ASTM F2753) ≤ 550 lbs. / sq. inch, with no forklift traffic

Abrasion Resistance

(EN660-2) Class T Wear Layer, Fv ≤ 2.0mm³

Flexibility

(ASTMF137) Passes

Resistance to Heat

(ASTM F1514) Passes

Resistance to Light

(ASTM F1515) Passes

Radiant Flux

(ASTM E648) Class I

Smoke Density

(ASTM E662) ≤ 450

Residual Indentation

(ASTM F1914) Passes

Resistance to Chemicals

(ASTM F925) Passes

Embodied Carbon (Cradle to Gate)

7.68 Kg CO₂/M²

Full Life Cycle Carbon Emissions

Carbon Neutral Floors™

Indoor Air Quality

GREENGUARD Gold

GREENGUARD Gold

Material Composition

Free of Ortho Phthalates, Added Formaldehyde and Heavy Metal Stabilizers

Disclosure of Environmental Impacts

Environmental Product Declaration

Disclosure of Product Ingredients

Health Product Declaration

LEED v4

Contributes to multiple IEQ and MR credits

Quantity per Roll

354.6 sf (32.9 m²)

Weight per Roll

238 lbs (108 kgs)

Rolls per Pallet

12

Pallets per Truckload

10

Installation

Interface Vinyl Sheet Installation Guidelines

Maintenance

Interface Vinyl Sheet Maintenance Guidelines

Warranty

15 Year Standard Vinyl Sheet Warranty

Installation Method

Directional

All product specifications reflect averages derived from product sample testing, are subject to normal manufacturing and testing tolerances and inherent pattern variances, and may be changed without notice. For more information about these and other important attributes of the product(s) described herein, including recycled content and product warranty information, please see www.interface.com/disclaimer.
