Drawn Lines
Drawn Lines
| Product Number |
A009 |
| Product Construction |
High Performance Luxury Vinyl Plank |
| Wear Layer Thickness |
0.55 mm |
| Total Thickness (Metric) |
4.5 mm |
| Classification |
EN 651 Class 42 (light industrial general) EN 651 Class 33 (heavy contract) |
| Acoustic Impact Noise Reduction |
ISO 10140-3 ΔLw = 16dB |
| Finish |
Ceramor™ UV stabilised Ceramic Bead Coating |
| Nominal Dimensions |
25cm x 100cm |
| Backing Type |
Sound Choice™ Acoustic Backing |
| Critical Heat Flux |
AS ISO 9239-1 >7kW/m2 |
| Smoke Rate |
AS ISO 9239-1 <750%.min |
| Size, Tolerance |
ISO 24342 <400 mm < 0.25 mm ISO 24342 >400 mm < 0.35 mm |
| Dimensional Stability |
ISO 23999 <0.25% |
| Thickness |
4.5 mm |
| Resistance to Light |
ISO 105-B02 ≥6 |
| Resistance to Heat |
ASTM F1514 ΔE< 8 avg Max |
| Resistance to Chemicals |
EN-ISO 26987 Passes |
| Reaction to Fire |
EN ISO 13501-1 Class BFI-S1 |
| VOC Test |
ISO 10580 Pass |
| Flexibility |
ISO 24344 Method A Pass |
| Static Load |
ASTM F970 ≤0.005" with 1500 psi |
| Castor chair |
ISO 4918 Pass |
| Thermal Conductivity |
EN 12667 0.16 W/mK |
| Static Electrical |
EN 1815 <2kV |
| Slip Resistance |
AS 4586:2013 R10 |
| Ingredients and Life Cycle Impacts | |
| Indoor Air Quality | |
| Recycled Content % |
39 % |
| Embodied Carbon (Cradle to Gate) |
9.2 kg CO₂ eq./m² |
| Sustainability Assessment |
NSF/ANSI 332, Meets Certification Guidelines |
| LEED v4 |
Contributes to IEQ: Low Emitting Materials; M&R: EPD and EPR |
| Installation | |
| Maintenance | |
| Warranty |
